DYMCO won the "technical prize" from the Japan Mechanical Engineers Society.

DYMCO won the "technical prize" from the Japan Mechanical Engineers Society as of NOV.25, 2011.

TITLE: DYMCO won the "technical prize" from the Japan Mechanical Engineers Society.

Steel Belt and Tracking 5. EPC / Edge Positioning Control

Another tracking method is EPC. Belt position is watched by sensors.

When sensors find that the belt is out of track, pulley shaft is moved to adjust tension on both belt width edges.

EPC is especially important when the operating temperature is over 150 degrees.

In the room temperature crown pulleys are used. Up to 150degrees V-guide is available.

But V-guide does not stand heat over 150 degrees.

Title: Steel Belt and Tracking 5. EPC / Edge Positioning Control

Steel Belt and Tracking: 4. V-guide

When V-guide is attached on a belt, we cannot apply much tension on the belt. We had better make belts as loose as possible. Also V-guide is made from rubber. Even silicon rubber stands 150 degrees C. These are tips for V-guide tracking.

Title: Steel Belt and Tracking: 4. V-guide

Steel Belt and Tracking: 3. V-guide

V-guide or V-rope is another method for tracking. When driving pulley axis and driven pulley axis are set in parallel and V-guide is forwarded straight, a belt does not wind.

V-guide is made of rubber. Chloroprene(CR) and silicon rubber are standard material. Nitrile rubber (NBR) can be an option.

Title: Steel Belt and Tracking: 3. V-guide

Steel Belt and Tracking: 2. Crown pulley

Crown pulley is the most popular tracking method for steel belts. For example, when pulley diameter is 100mmand belt size is thickness 0.2mm and width 200mm, curvature radius is R50,000.

This is same as crown height 0.1mm.It is significantly minute compared with millimeter-order crown height for plastic and rubber belts.

Yet crown pulley sometimes does not work, when belts are very thick, very wide, very long, or due to other factors such as conveyor structure and assembly precision.

Title: Steel Belt and Tracking: 2. Crown pulley

Steel Belt and Tracking: 1. Crown pulley and Flange pulley

Due consideration should be paid to tracking in choice of belts. When a belt does not move straight in running direction, it may come off pulleys and rotation halts. When we talk about endless belts without perforation, very popular tracking method is ‘crown pulley.’ We do not recommend flange pulleys. It is true that when belt width is just around 10 to 20mm, tracking is done by flange pulleys. But in general belt width edges are damaged by flanges.

Title: Steel Belt and Tracking: 1. Crown pulley and Flange pulley

DYMCO: Certified as Yokohama Chizai Mirai Enterprise

On September 1^st DYMCO, LTD. was certified as Yokohama Chizai Mirai Enterprise by the City government of Yokohama.

Our business management is evaluated in view of intellectual assets in line with business plans to capture industrial needs in the future.

Title: DYMCO: Certified as Yokohama Chizai Mirai Enterprise

Moved to Fukuura Research center as of July 25

We, Dymco Overseas department moved to Fukuura Research center as of July 25.

If you would like to contact us on steel belts products, please kindly use the below Tel & Fax no.

Tel: +81-45-780-5570

Fax:+81-45-701-6830

Fukuura is quite near to Hakkeijima and Sea Park where you can get sea shells in spring and summer time.

Title: Moved to Fukuura Research center as of July 25

FOR SHEET FORMING - DYMCO Seamless steel belt and Air roll! Convertech China 2011

Convertech China 2011/07/07 http://www.convertechchina.com/

JULY 6 Wed. – July 9 Sat.

At Shanghai New International Expo Centre

Dymco Machinery (Shanghai) Co, Ltd. Booth: E5 Hall No.5089

DYMCO Metal Sleeve 1

I am Ohashi at the Engineering Department, steel belt DYMCO Fukuura research center.

DYMCO Metal Sleeves are used for the copier and the resin film molding machine, etc.

Dymco producible range

- Diameter: 10mm to 1000mm.

- Thickness: 0.03mm to 1.0mm.

The small and thin metal sleeves (diameter less than 50mm, thickness less than 0.1mm) are often processed from seamless tubes and molded with the press. We have various materials for the small and thin metal sleeves.

Title: DYMCO Metal Sleeve 1

DYMCO started Korean Blog

We have started Korean Blog : http://ameblo.jp/steelbeltdymco . We have a Korean speaking staff in DYMCO. If you have any inquiries on DYMCO STEEL BELTS, please contact us without any hesitation in English or Korean.

Title: DYMCO started Korean Blog

Message from DYMCO PRESIDENT

Two months have passed from the huge earthquake of 3.11. We sincerely send our sincere sympathies to everyone who has struck by this East Japan great earthquake.

We feel very sad every time when we see the article in a newspaper and the TV news. It cannot be without feeling powerlessness in me who cannot do anything.

In this situation, what we should do is we should do what we can do the best.

Although it is indirectly, DYMCO steel belts and stainless tubes are related to the solar battery, the lithium-ion battery, organic EL, and FPD, which is necessary indispensability of the society.

We work hard so that the customer will be satisfied with DYMCO Products and without forgetting pleasure and thank to be able to do this work.

TITLE: Message from DYMCO PRESIDENT

Steel Belt (36) DYMCO New Product as Kanagawa Standard

This is Yamato of Steel Belt Dymco.

Kanagawa Prefecture recognizes DYMCO New Product as Kanagawa Standard.

New technologies and new products of the small and medium-sized enterprises in Kanagawa Prefecture, evaluate to be suitable from both sides of the technology and management to the world as a high technology from Kanagawa. The recognition presentation was held in Pacifico Yokohama. We will provide DYMCO Steel Belt Products to the customer with confidence.

Title: Steel Belt (36) DYMCO New Product as Kanagawa Standard

Steel Belt (35) Silicon rubber on the Steel Belt

I am Nagaya, sales responsible of Steel Belt DYMCO. On this time, I will introduce one case of the steel belt for transportation.

Previously I received an inquiry from one customer: " Is it possible to install the work guide at both ends of the steel belt surface? Because the work is a globe shape so it is easy to spilt from the belt."

It is very difficult for the material to paste and apply the work guide to the total length for the steel belt surface as it is made of the stainless steel (metal).

However, silicon rubber was put on both ends of the surface of the steel belt after many Tests and we served it to the customer.

Please refer to the above photograph.

If you have a question “Can you do this with the steel belt?”, please inquire to DYMCO by all means.

Title: Steel Belt (35) Silicon rubber on the Steel Belt

Steel Belt (34) Steel Belt DYMCO: Made of Stainless Steel

I am Sakae of Overseas Business Department. Thank you always for your supports to Steel Belt DYMCO.

Recently I have bought a kitchen knife at the department store in Yokohama. Roughly the kitchen knives are made of the Stainless steel or Steel.

Shop clerk’s recommendation was the Steel kitchen knife. Actually this steel knife has wonderful sharpness, not heavy and also the design was classic and beautiful. But the weak point is easy to rust.

For Stainless Steel knives, it is easy to care because the stainless steel doesn't rust. However, on this time I bought a Steel knife because I was attracted by its wonderful sharpness. I used several times and every time I should wipe it beautifully after use. I will buy the stainless steel kitchen knife next time.

The stainless steel belt doesn't rust either. Moreover, DYMCO stainless steel belts have chemical resistance and heatproof characteristics. DYMCO Stainless Steel Belt is the best for usage under the severe environment. We look forward to receiving your inquiries.

Tittle: Steel Belt (34) Steel Belt DYMCO: Made of Stainless Steel
